Running a seismic survey near Cross Lake versus a site in the Youree Drive commercial corridor reveals completely different velocity profiles. One sits on soft Quaternary alluvium. The other hits stiff Cook Mountain Formation clay at 15 feet. You cannot apply the same Site Class to both. Shreveport's subsurface varies block by block. Our MASW testing maps these transitions precisely. We deploy 24-channel arrays to capture fundamental-mode Rayleigh wave dispersion. The result is a measured VS30 value that replaces generic defaults in ASCE 7. For deep Red River deposits, combining MASW with seismic refraction resolves low-velocity zones hidden beneath faster surface layers. Engineers designing in Shreveport's seismic Zone B need this data for IBC Chapter 16 compliance.
A measured VS30 of 245 m/s versus an assumed 350 m/s changes your seismic base shear by over 30 percent in Shreveport.
Process and scope
Site-specific factors
Shreveport sits at 154 feet above sea level on a gradual slope toward the Red River floodplain. The USGS National Seismic Hazard Model assigns the area a 2% probability of exceeding 0.15g peak ground acceleration in 50 years. Not high by West Coast standards, but Site Class amplification multiplies that motion. A Site Class E profile can amplify short-period acceleration by a factor of 2.5 compared to rock. The 2015 USGS update refined the deep soil basin model for the Gulf Coastal Plain. Using default Site Class D without measurement means you either overbuild or under-design. Neither is acceptable. The IBC requires a site-specific geophysical investigation when soil conditions are not clearly Class C or better. Soft Red River silts and backswamp deposits in southern Shreveport almost always warrant a measured VS30.
Watch the video
Standards used
ASCE 7-22 (Minimum Design Loads, Chapter 20 Site Classification), IBC 2021 Section 1613 (Earthquake Loads, Site Class Determination), ASTM D7400 (Standard Test Methods for Downhole Seismic Testing, adapted for surface wave methods), USGS National Seismic Hazard Model (Gulf Coastal Plain basin amplification)
Complementary services
VS30 Site Classification
One-day field acquisition with 24-channel seismograph. We deliver a signed report with dispersion curves, 1D velocity profile, and computed VS30 for IBC/ASCE 7 Site Class A through E designation.
Deep Basin Velocity Profiling
For tall structures requiring site-specific ground motion analysis. Extended 276 ft spreads resolve shear velocity to 130 ft depth, characterizing the Tertiary-to-Quaternary transition common beneath Shreveport.
Shear Modulus (Gmax) Mapping
Converts VS profiles to small-strain shear modulus for finite element soil-structure interaction models. Used in deep excavation and retaining wall design where soil stiffness governs deformation.
Typical parameters
FAQ
What VS30 range triggers Site Class E in Shreveport?
Site Class E applies when VS30 falls below 600 ft/s (180 m/s). In Shreveport, this commonly occurs in the Red River alluvial floodplain and backswamp deposits south of downtown. The soft clays and loose silts in these areas often yield VS30 values between 450 and 590 ft/s, placing them squarely in Class E. A measured profile is the only reliable way to confirm this.
How long does a MASW survey take on site?
A standard 138 ft spread with three shot locations takes approximately 2 hours of field time. This includes geophone planting, cable layout, and data acquisition. Sites with asphalt or concrete require drilling through the pavement at each geophone location, adding about 30 minutes. We can typically complete two to three lines in a single day in Shreveport.
What does a MASW / VS30 survey cost for a Shreveport commercial project?
For a commercial building site in Shreveport, a single MASW line with full processing, dispersion analysis, inversion, and a signed VS30 report typically ranges from US$1,860 to US$3,490. The final cost depends on the number of lines, surface conditions, and whether deep profiling beyond the standard 100 ft depth is required.
Can MASW replace a downhole seismic test for IBC compliance?
Yes, when performed and processed correctly. IBC Section 1613.3.2 accepts shear wave velocity measurements from geophysical methods including surface wave techniques. MASW is specifically recognized as a valid method for determining VS30 for site classification. Active-source MASW provides higher lateral resolution than a single downhole boring, averaging velocity over the full array length rather than a single borehole.
